DESCRIPTION:
Features as adjustable beam angle, wireless control adjustable wattage. It can be widely used in manufacturing, warehouse, logistics center, exhibition hall and other scenes.
² Wattage: Adjustable in 3 gears 150W-100W-200W
² Color temperature: Adjustable CCT 3000K-4000K-5700K &4000K-5000K-6500K
² Luminous efficacy:170lm/W
² Optic: Adjustable 60°/90°
² Protection: IP65, IK08
² Dimming: 0-10V, Dali 2(D4I)
² Installation: Suspending, Derrick, Bracket
PRODUCT SPECIFICATION
|
INPUT |
200V~240V AC |
||
|
WATTAGE |
200W (DIP Switch) |
150W (DIP Switch) |
100W (DIP Switch) |
|
LUMEN |
34000LM |
25500LM |
17000LM |
|
DIMMING |
0~10V; DALI 2 D4I |
||
|
SURGE PROTECT |
L/N-G>4KV & L-N>4KV |
||
|
PF |
>0.9 |
||
|
PROTECTION |
Short-Circuit Protection & Over-Voltage Protection & Overheat Protection |
||
|
CCT ADJUSTABLE |
3000K-4000K-5700K & 4000K-5000K-6500K |
||
|
OPTIC |
60° & 90° Adjustable |
||
|
CONSTRUCTION |
Aluminum |
||
|
N. W |
2.75 KG |
||
|
SIZE |
Ø325*108mm |
||
